Product Information

We develop a check, measurement and a control system in the manufacturing site as the total solution company of a appearance check system by image processing and carry systematization of appearance check and automation for watch. Introduction of the automatic appearance check system to get in touch with quality guarantee and rationalization already is urgent business and also diversifies needs in the various industry world.
The experience and the results which have design and production of a circuit and a substrate, development of software, design and production of hardware, and development of an optical system as a herald of image processing industry since foundation in 1981, and, the appearance check system that the user responded to the demand for products of all fields has been offered. Our main product is introduced to the following, but minute defect test of a metal component, a resin mold and a glass part, etc. also has good introduction results besides those. YM SYSTEMS have many users use our check system as quality control standard.
Please inquire about details of the respective products.

Printout Character Check System

Check equipment which corresponds to all printout characters which include thermal printers, laser printout and rubber stamp letters widely.
It's possible to calculate the check pattern of the use-by date automatically and check it by 100ms per 10 characters. It's possible to register all alphanumerics, kanji and symbols every kind. The detailed inspection function of the feature territory where a presence of the character is checked is loaded into particular part. A highly precise check is achieved.

The Dot Printout Character Check System

Check equipment which corresponds to the dot character.
It's possible to calculate the check pattern of the use-by date automatically and check it by 100ms per 10 characters. It's possible to register all alphanumerics, kanji and symbols every kind. The detailed inspection function of the feature territory where a presence of the dot character is checked is loaded into particular part. A highly precise check is achieved.

Print Check System

This check system made the defect detection of color printed matter possible by high speed and high resolution.
Parameter setting and numerical value input can be done by easy mouse operation. The customization by which a card cash voucher, a label seat and catalog, and a brochure, poster and postcard respond to all needs variously, possible.
We also have OEM supply.

Food Tampering Automatic Appearance Check System

The check equipment in which tampering of a hair in a food manufacturing process, a plastic fragment and all material of the metal fragment is detected visually.
It's possible to distinguish between the shape of the hair by the first image processing optimized by a forward genetic algorithm and distinguish from the figure easy for secomndary processing algorithm to falsely recognize. The biggest detection capability is achieved.

Alien Substance in The Liquid Check System

The alien substance in the liquid filled into transparency or a semitransparent container (plastic bottles and lamicon bottles, etc.) is detected automatically.
It's possible to detect an alien substance of a rubber fragment, mark tube and cushioning material, hair etc.. It's possible to set check territory optionally setting to the surface form of the container. A stable more check is achieved by adjusting the check precision every territory.

Three-Dimensional Image Measurement System

The equipment of height measurement by the three-dimensional image processing to which grid projection phase shift method was applied.
10 ﾊm of measurement system and measurement time for 0.5 seconds. It's also possible to measure minute unevenness in real time. Positioning equipment of a weld and an automatic register system of tableware, it's possible to apply to all equipment.

Real Time Minute Surface Displaced Measuring System

The displaced measuring equipment which gauges height measurement in the object surface with high precision of real time and a nanometer order.
It suits height measurement in the surface of the object which changes minutely partially with time. It's possible to apply to minute height measurement of unevenness and roughness measurement in the surface.

Mark Appearance Check System

The appearance check equipment for a print check of a circular electronic component of aluminum electrolytic capacitor.
It's able to pick the part shape out even in photography picture of the complicated background and texture. A highly precise check of template pattern matching of 1 character unit was achieved by high speed and the correct spin compensation function. At most 4 of CCD camera can be connected. The processing power, 0.1 seconds for 1.

The Number of Packages Check System

It's checked whether the imaging number of packages which do and enter per 1 box is right by CCD camera just before packing packaged goods in a manufacturing process of the snack, etc..
It's possible to add a visual check as well as the weight check and the reliability of the goods rises

Edge-Polishing Width Measuring System

It's high-speed and the edge-polishing width of the liquid crystal glass substrates is measured correctly.
It's possible to measure on-line off-line both. It can correspond to the size of glass substrates of everything, and a series of manufacturing process can be automated by in-lineize, also a grinder and a washing machine.

Plastic Quality Evaluation System for PET Bottle Recycling

The device which it is highly precise, and inspects the alien substances such as dust or impurities included in the plastic to use for recycling.
This machine distinguishes the alien substances of approximately 30μm in diameter with a line type sensor. It is a technique to enable the conversion to the recycling product of high quality.

New High-Performance Hair Check System

This tester put GPGPU adopted to a super computer in our development image equipment "XXOA" together and succeeded in detecting a hair by a near method in the judgment due to the human eyes and brain.
The thickness of the hair that the device is detectable is 10mm in length or more at 35-150μm, and the color of the hair is no object. This system adopts new detection algorithm and is the device which is high-performance for low price.
